Precast Compound Wall Manufacturers
Category: Compound Walls Available for Delivery

Precast Compound Wall Manufacturers

Direct manufacturing unit of precast compound walls serving residential layouts, factories, educational institutions, and warehouses.

High Strength
Fast Installation
Weather Proof
Low Maintenance
M30 Grade
High Strength Mix
10+ Years
Life Expectancy
Factory Direct
Best Price
IS Certified
Quality Assured

Product Overview & Applications

Direct from our state-of-the-art casting yard in Amarpatan, Satna. We employ modern mechanical vibrators and high-precision steel molds to produce compound wall panels with mirror-smooth surfaces and robust structural cores.

Key Applications

Farmland & Farmhouses
Factories & Godowns
Residential Plots & Colonies
Drain Covers & RCC Slabs

Key Features & Benefits

High Strength
Direct manufacturer rates with no middleman margins
Fast Installation
Daily high volume production capacity
Weather Proof
Full testing facility for batch concrete cubes
Low Maintenance
Complete supply and erection service available
Cost Effective
Proven track record with 10+ years excellence

3D Technical Blueprint

▼ GROUND LEVEL POST SPAN: 7 FEET (2100mm c/c) 1 2 3 4 5

Technical Specifications

Production Capacity 1,500 running feet / week
Concrete Mix Designed M30 mix
Post Spec 150mm x 150mm with 7 grooves for panels
Panel Reinforcement 4 nos 3.0mm high-tensile wire
Guarantee Long lasting structural stability

Numbered Component Dimensions & Engineering Key

1
Slotted H-Column (Pillar)
150mm x 150mm (6" x 6")

Dual-groove reinforced column with high structural stiffness.

2
Stacked Interlocking Panels
2100mm x 300mm x 50mm

Multi-tier tongue & groove precast slabs slid between posts.

3
Center-to-Center Post Span
7 Feet (2100mm c/c)

Standard bay spacing offering optimal strength and economy.

4
Above-Ground Wall Height
6ft to 12ft Options

Customizable boundary height for plots, farms, and factories.

5
Underground Concrete Footing
2.5ft to 3ft Embedment

Cast-in-place concrete foundation collar for anti-tilt stability.
